Specifications	Units	XK7126	XH7126
工作臺尺寸Table size	mm	800x260	800x260
X軸行程X axis travel	mm	450	450
Y軸行程Y axis travel	mm	320	320
Z軸行程Z axis travel	mm	400	400
工作臺更大承重Max. worktable load	kg	200	200
T型槽（數量-寬度-間隙）		3-14x80	3-14x80
T slot(number-width-pitch)		3-14x80	3-14x80
主軸轉速M(fèi)ax. spindle speed	rpm	6000	6000
主軸錐度Spindle taper	mm	BT40	BT40
主電機功率Main motor power	kw	3.7	3.7
X/Y/Z軸快移速度	m/min	15/15/15	15/15/15
X/Y/Z rapid traverse speed	m/min	15/15/15	15/15/15
切削進給速度Cutting feed speed	mm/min	1-6000	1-6000
導軌形式Guide rail type		Linear rail	Linear rail
主軸中心到立柱表面距離	mm	360	360
Distance from spindle axis to column surface	mm	360	360
主軸端部到工作臺表面距離	mm	90-520	90-520
Distance between spindle nose and worktable surface	mm	90-520	90-520
定位精度Positioning accuracy	mm	±0.015	±0.015
重復定位精度Repeat positioning accuracy	mm	±0.0075	±0.0075
刀庫Tool magazine		-	12 Armless/(Optional: Arm 16 )
刀具更大直徑Max. tool diameter	mm	-	130
刀具更大重量Max.tool weight	kg	-	8
機床重量Machine weight	kg	2100	2400
外形尺寸Overall dimension	mm	2200x1900x2200	2200x1900x2200
